SPECIFICATION
|
AC INPUT
|
|
| Model |
PBZ 550W 80+ Bronze |
| Form Factor |
ATX |
| Dimensions |
140(L) x 150(W) x 85(H)mm |
| Voltage Range |
90 – 260V |
| Current |
6A |
| Frequency |
47 – 63Hz |
| Color |
White |
| 80 PLUS Certification |
Bronze |
DC OUTPUT
|
|
| Red |
+5V (10A) |
| Orange |
+3.3V (10A) |
| Yellow |
+12V (45A) |
| Blue |
-12V (0.3A) |
| Purple |
+5Vsb (2.0A) |
POWER CONNECTOR
|
|
| Main Power (24 pin) |
1 |
| ATX 12V (4+4 pin) |
1 |
| PCI-E (6+2 pin) |
2 |
| Sata (4 pin) |
4 |
| Safety Features |
OVP (Over Voltage Protection) |
|
SCP (Short Circuit Protection) |
|
UVP (Under Voltage Protection) |
|
OPP (Over Power Protection) |
80 PLUS CERTIFICATION
|
|
| Based data from |
| *https://www.plugloadsolutions.com/80PlusPowerSuppliesDetail.aspx?id=115&type=2 |
