SPECIFICATION
|
| Processor |
Intel ® Socket 1151 for 6th Generation Core™ i7 / i5 / i3 processors |
| Chipset |
Intel® B250 |
| Memory |
Dual Channel DDR4 3000/2800/2400/2133 MHz Memory up to 32 GB |
| Dimm |
2 x Memory Slots (Max. up to 16GB each) |
| Onboards Graphics |
Intel® HD Graphics |
| LAN |
RTL8105E 1000 Mbps ethernet on board |
| Audio |
Realtek ALC662 integrated on board |
| Slot |
1 x PCI Express x16 Slot |
| SATA |
4 x SATA III port |
|
|
| On Board Pinheaders / Connectors |
2 x USB 2.0 pinheader supports additional 2 USB 2.0 ports |
|
1 x USB 3.0 pinheader supports additional 2 USB 2.0 ports |
|
1 x Front Panel Audio pinheader |
| Form Factor |
Micro ATX (19.6 x 16.8 cm) |
| Back I/O Ports |
1 x M.2 Slots |
|
1 x PS/2 Mouse port |
|
1 x PS/2 Keyboard port |
|
1 x VGA port |
|
1 x DVI port |
|
4 x USB 2.0 port |
|
2 x USB 3.0 port |
|
1 x LAN jack |
|
3 x Audio Jack |
| Accessories |
1 x Driver CD |
|
1 x User Manual / Warranty |
|
1 x I/O Backboard |
|
1 x SATA Cable |
